| Model |
AB-GADN1154-3202 |
AB-GADN1156-3202 |
| Detection |
Vehicle: 8.6km,Human:3.4km |
| Identification |
Vehicle:2.4km, Human: 900m |
| Thermal Camera System |
| Sensor |
5th generation FPA VOx uncooled detector |
| 384*288 resolution |
640*512 resolution |
| Spectral range |
7.5~14μm |
| NETD |
50mK (@25℃ F1.0) |
| Focal length |
25mm~105mm, 5X continuous zoom, auto focus |
| FOV |
18.5°*13.9°~3.7°*2.8° |
30°* 23°~6.2°*4.6° |
| Image process |
1. Image enhancement: SDE digital image enhancement technology to enhance image details
2. Pseudo-color polarity: 16 kinds of pseudo-color images, hot black / hot white two polarities
3. Image parameters: AGC automatic gain control, brightness, contrast
4. Electronic zoom: 2×, 4×, support global synchronous display
5. NUC correction: automatic / manual correction, background correction |
| Lens Control |
1.Zooming: Electrical Zoom. 2.Focusing: Manual/Auto Focus
3. Optical machine: 3CAM mode and AS+DOE optical structure, high infrared over transmission, zoom process without virtual focus, smaller axis. |
| Visible Camera System |
| Camera |
1/2.8” star level CMOS, 0.05lux/0.01lux color to B/W CCD |
| 2 MP ,1920X1080 |
| Automatic ICR switch |
| H.264/H.265 MPEG4/MIPEG |
| 32Kbps~16Mbps,60Hz30 FPS |
| Visible lens |
8mm~320mm, 2MP, 40X zoom, auto focus |
| Optical IR correction design, diurnal focus |
| Housing |
| Material |
High strength aluminum alloy shell,waterproof seal,To avoid the growth of mold and moisture generated |
| Structure |
Integrated single-window design |
| Surface coating |
PTA three-resistance coating, Seawater corrosion resistance |
| Temp. Control |
Built-in thermostat, design of thermal equilibrium |
| Interface |
Aviation waterproof plug |
| PTZ |
| Load Capacity |
30kg |
| Range/Speed |
Range:Pan: 0~360°, Tilt: +45°~-45°; Speed: Pan: 0.01~60°/S, Tilt: 0.01~30°/S |
| Preset |
255 |
| Scan |
Support 6 cruising line, 1 apple-skin scanning, 1 line-cruising. |
| Interface |
| Network Interface |
RJ45 |
| Network Protocol |
Support TCP/IP, UDP, IPv4/v6; Support HTTP,RTP,RTSP,NFS,HDCP,NTP,SMTP,,PPPoE,DNS, FTP, Onvif |
| Power Supply |
AC/DC24V, anti-reverse connection protection |
| Environment Parameter |
| Working/Storage Temp. |
Working temperature: -25℃~+60℃(-40℃for optional); Storage temperature: -45℃~70℃ |
| Seismic/Impact Resistance |
0.2g/15g |
| Anti-lighting |
Built-in auto Fuse-protected device, Power 4000V,Signal 2000V |
| Weight & Power Consumption |
Weight: 35kg (include PT); Power consumption: 150W
|
